Main 3 in 1 TCB TH600pro

Model: TH600pro

*MIC:

 Frequency Range: 22-200000Hz

 Frequency Response: ±1.5dB

 SNR: >98dB

THD+N: <0.05%

Dynamic Range: ADC 105dB, DAC 103dB

Maximum Input Level: 180mVrms/-15dBV

Input Interface: 2 MIC，A/B

 Parametric Equalization: (63Hz,125Hz,250Hz,500HZ,1KHz,2KHz,4KHz,6.3KHz,8KHz,10KHz)５段(125Hz,250Hz,1KHz,2.5KHz,8KHz)５(125Hz,250Hz,1KHz,2.5KHz,8KHz)+/-6dB,PC+/-24dB

 Xover: 12/18/24dB

 FBX: 4

HDMI: 4-1 2.0

*MUSIC:

Frequency Range: 22-20000Hz

 Frequency Response: ±1.5dB

 SNR: >98dB

THD+N: <0.05%

Dynamic Range: ADC 105dB, DAC 103dB

Maximum Input Level: 3Vrms/8dBV

Maximum Output Level: 69Vrms/600W 8Ω

 Noise Level: <-90dBu

Input Interface: (VOD/AUX),(Optical),(Coaxial),HDMI,USB

Output Interface: 6 lotus 5.1 channel outputs

 Parametric Equalization: 7(125Hz,250Hz,500Hz,1KHz,2KHz,4KHz,8KHz)+/-6dB,PC+/-24dB

 Xover: 12/18/24dB

Power Consumption: 220VAC +/-10%

 Weight: 14.3kg

 Size: L429*D386*H102mm
